Kenwood DMX5020BTS | Bluetooth | 6,8' TFT Touch | Apple CarPlay & Android Auto | Autoradio
-kein CD / DVD-
Key Features
| 6.8" WVGA Capacitive Touch screen - White Key Illumination |
| Apple CarPlay® & Android Auto™ Ready |
| Android USB Mirorring Ready |
| Built-in Bluetooth |
| Bluetooth wireless music browsing ready |
| 2 Preouts + subwoofer (2.0V) |
| 13 Band EQ - DSP - DTA Built-in |
| AV-in or Camera-in (Selectable) / AV-out |
| Rear Camera input with built-in parking guide lines |
| Short Chassis for easy installation |
General Features
| DIN Size | 2 DIN |
| Smooth GUI | Yes |
| Selectable GUI Background Wallpaper | Yes |
| Key Illumination | White color |
| Back-up Memory | Yes |
| Attenuator with Smooth Volume Return | Yes |
| Touch Sensor Tone | Yes |
| Optional IR remote controller | Yes, (KNA-RCDV331) |
| Digital Clock (24H) | Yes |
| ISO connector | Yes |
| Bluetooth unit built-in | Yes |
| Made for iPod | Yes |
| Works with Apple CarPlay | Yes |
| Works with Android Auto | Yes |
| USB 1 wire Mirroring for Android | Yes |
| Firmware upgreadable | Yes |
Monitor Features
| Screen Type | 6.8" Wide VGA |
| Display Mode | 4 Mode (Full/Zoom/Normal/Auto) |
| Screen Adjustments | Brightness / Tint / Color / Contrast |
| Dimmer function | Manual/Sync |
| Dimmer Level | yes |
| Visual Source Mode | Mirorring / CarPlay / Android Auto. |
| Display Type | Glare |
| Display film | Anti Fingerprint |
| Display Panel | Capacitive |
| Mechanism type | Fixed |
| NTSC/PAL judge | Yes (Auto) |
| Display Off Mode | Yes |
Multimedia GUI Features
| OSDC Type | Graphic |
| Menu text | 14 languages:
? English(UK)(Default)
? English(US)
? Spanish
? French
? German
? Italian
? Dutch
? Russian
? Portuguese
? Hebrew
? Greek
? Polish
? Czech
? Hungarian |
| Software updates (SoC) | |
| Demonstration Mode | Yes |
| Top Menu Customize | Yes |
| Opening Screen Type | standard |
| Background Customize | 6 x presets + 2 x user set |
| R-CAM interrupt | Yes |
| R-CAM Parking Guide Lines | Yes |
Tuner Features
| Station Select | Manual / Preset (List) |
| FM Reception | Yes |
| AM (MW/LW) Reception | Yes |
| Tuner Presets (FM/AM) | 20 Presets (15FM / 15AM) |
| Tuning mode | Auto1/Auto2/Manual |
| Up/Down Seek/Scan | Yes |
| Automatic Memory Entry (AME) | Yes |
| FM Stereo / Mono Selector | Yes |
| Radio Data System | Yes |
| Radio Text Plus | Yes |
| Traffic Information | Yes |
| Local search | Yes |
| AF Regional | Selectable: AF/AF Reg/OFF |
| Enhanced Other Networks Function (EON) | Yes |
| Program Type Function (PTY) | Yes |
Bluetooth General Features
| Hands Free Profile (HPF) | V1.6 |
| Hands Free Profile with High Sound Quality | HFP V1.6 |
| Audio Streaming (A2DP) | Yes, (SBC/AAC) |
| Serial Port Profile (SPP) | Yes |
| Simple Secure Pairing (SSP) | Yes |
| Phonebook Access Profile (PBAP) | Yes |
| Generic Access Profile (GAP) | Yes |
| Service Discovery Profile (SDP) | Yes |
| Audio/Video Remote Control Profile (AVRCP) | Yes, V1.5 |
| Catchphone / Call Waiting | Yes |
| Private mode | Yes |
| Alphabet Search (Phonebook) | Yes |
| Voice Control | Yes |
| Noise Canceller | Yes |
| Echo Canceller | Yes |
| Signal strength display | Yes |
| Remaining battery display | Yes |
| Bluetooth Paring Indicator | Yes |
| High-quality noise canceling microphone | included |
| Bluetooth firmware upgradeable | Yes, Included in system updates |
CE_Playable Audio file
| AAC (*.aac) files are playable | USB |
| MP3 files are playable | USB |
| WMA (.wma) files are playable | USB |
| WAV (.wav) files are playable | USB |
| FLAC files are playable | USB |
CE_Playable Video file
| MPEG1/2 files are playable | USB |
| MPEG4 files are playable | USB |
| WMV files are playable | USB |
| H.264 files are playable | USB |
| mkv files are playable | USB |
| JPEG files are playable | USB |
USB Features
| USB terminal | Yes, rear side / 1m cable / fix |
| USB Type | 2.0 High speed |
| Works with Android Auto | Yes |
| Works with Apple CarPlay | Yes |
| USB Mirroring for Android | install "Mirroring OA for KENWOOD" from Playstore |
| Repeat Play | Folder/File/All |
| Random play | Folder |
| Category search | Yes |
| Link Search | Yes |
| Resume play | Yes |
| Time code display | Yes |
| 1,5A Smartphone Quick Charge | Yes |
Audio features
| Max. Output Power (MOSFET Power IC) | 4 x 45W |
| Pre-out | 2 RCA : FRONT/REAR + SUB(mono) |
| Pre-out Output Level | 2V |
| Volume Offset | Yes |
| Balance/Fader Control | Yes |
| Att.(-20dB) with smooth Volume Return | Yes |
| Digital Sound Processor (DSP) | Yes |
| Beep On/Off | Yes |
Multimedia DSP Features
| Car type control | ? Off
? Compact
? Sedan
? Wagon
? Minivan
? SUV
? Passenger Van |
| Speaker Size & Location Control | Yes |
| X'over network | 2-way X'over / HPF / LPF |
| Listening postion control / Time Alignment | Yes |
| Equalizer type | Graphical |
| Equalizer | 13-Bands |
| Equalizer presets / User set | 7 presets / 4 User set |
| Balance & Fader Control | Yes |
| Source Volulme Offset | source independent |
| Sound Effects | ? Off
? Compact
? Sedan
? Wagon
? Minivan
? SUV
? Passenger Van |
| Audio Setup Memory | Yes |
Video Features
| Audio Video Output | Yes, Video only (RCA) |
| Audio/Video Input | Yes, AV-input or Camera input (Selectable) |
| Video-In for Rear-view Camera | 1 dedicated video input (RCA) |
| Detection Mode Rear View Camera | Reverse sensor wire |
| Parking Guide Line | Yes |
Connectivity
| OEM Wired Remote Control ready | Yes, Optional interface needed |
| Programmable OEM Steeringwheel Remote Function | Yes |
| Parking sensor (handbrake) wire | Yes |
| Power Control (P.CON) wire | Yes |
| Dimmer control wire | Yes |
| Preout | 2 x RCA (Front/rear) + Sub (mono) |
| AV-Input | 1x mini-jack (selectable: AV-in / Camera-in) |
| Video Out | RCA x1 |
| Reverse sensor wire | Yes |
| Rear View Camera Input | Dedicated RCA Video-in |
| FM Antenna Input | JASO connector |
| External microphone input | 3,5mm mini-jack |
Tuner Specifications
| FM range: 87.5Mhz - 108MHz (50Khz step) | Yes |
| FM Usable Sensitivity | 1.8?V/75ohm (S/N 30dBf) |
| FM Frequency Response | 30Hz 14kHz (± 3dB) |
| FM Signal to noise ratio (Mono) | 50dB |
| FM Stereo Separation (1kHz) | 35dB |
| MW range: 531kHz - 1611kHz (9kHz step) | Yes |
| MW Usable Sensitivity | 99?V |
Bluetooth specifications
| Technology | Bluetooth V4.1 |
| Frequency | 2.402 - 2.48 GHz |
| Output power | +8dBm(max), power class 1 |
| Maximum range | Line of sight approx. 10 meter |
| Handsfree profile (HFP) | Yes, V 1.6 |
| Serial port profile (SPP) | Yes |
| Advanced audio distribution profile (A2DP) | Yes |
| Audio Codec | SBC/AAC |
| Phonebook access profile (PBAP) | Yes |
USB Specifications
| USB Version compatibility | USB 2.0 High Speed |
| File System | FAT 16/32, exFAT |
| Maximum Supply current | 1500mA |
| D/A Converter | 24bit |
| Video Decoder | MPEG1/2/4, WMV, H.264, mkv |
| Audio Decoder | MP3, WMA, AAC, WAV, FLAC |
Audio Specifications
| Maximum Power | 45W x 4 |
| Output Power (DIN45324,+B=14.4v) | 21W x 4 |
| Output frequency band | 20Hz 20kHz |
| Preout Level | 2000mV / 10kOhm, |
| Preout Impedance | ? 1400Ohm |
| Speaker Impedance | 4Ohm 8Ohm |
DSP Specifications
| Frequency band - Front | 62.5Hz 16kHz |
| Equalizer Gain | –9db +9db |
| 2-Way X'over / Front/Rear (HPF) / Frequency | trough/30/ ... /220/250Hz |
| 2-Way X'over / Front/Rear (HPF) / Slope | -6/-12/-18/-24 (dB/oct) |
| 2-Way X'over / Subwoofer (LPF) / Frequency | 30/40/ ...250Hz/Through |
| 2-Way X'over / Subwoofer (LPF) / Slope | -6/-12/-18/-24 (dB/oct) |
| Position: 2-Way (Front/Rear/Sub)Delay | 0cm 610cm (1cm step) |
| Subwoofer Level | -40dB 6dB |
| Equalizer Type | Graphic |
| Frequency band | 13 bands |
Video Specifications
| Color System of External Video Input | NTSC/PAL |
| External video input level (mini-jack) | 1 Vpp / 75 Ohm |
| External Audio Max. Input Level (RCA) | 1.5 V / 25 kOhm |
Monitor Specifications
| Screen size (Diagonal) | 6.75 Inches Wide |
| Screen Size (WxH) | 151.8 x 79.7mm |
| Display system | Transparent TN LCD Panel |
| Drive system | TFT Active Matrix System |
| Number of Pixels | 1152000pixels (800(H) x 480(V) x RGB) |
| Effective pixels | 99.99% |
| Pixel arrangement | RGB Striped |
| Back lighting | LED (Light Emitting Diode) |
General Specifications
| Operating voltage | 14.4V (10.5 16V Allowable) |
| Dimensions (WxHxD) | 178 x 100 x 75mm |
| Weight | 1.1 gr. |
| Weight, inclu. sleeve & escutcheon | 1.3 kg |
Accessories
| Release keys | 2 pieces |
| Escutcheon | Yes |
| Installation Sleeve | Yes |
| Handsfree Microphone | with 3 m cable |
| Multi-Language Instruction Manual Included |
14.4
Stromaufnahme [A]:<10A
Breite [mm]:178
Höhe [mm]:100
Tiefe [mm]:75
Größe:2 DIN
Bildschirmdiagonale [Zoll]:6.8
Bildschirmauflösung:800х480
Bildschirmanzeige:TFT
Leistung [W]:4x45
Kurze Ausführung:+
Bluetooth:Ja
Mikrofon:Ja
Anschlüsse:USB, RCA, AUX in
Unterstützt:Apple CarPlay, Android Auto
Eigenschaften:Mit Lenkradfernbedienung, mit USB-Anschluss, Bluetooth
Funktion Einparkhilfe:Parklinien
Audio format:MP3, WAV, WMA, FLAC, AAC
Video format:MPEG1, MPEG2, MPEG4, H.264, mkv, WMV
Foto-Dateiformat:JPEG
Ausgangsstromstärke USB [mA]:1.5
- Produktfarbe:
- Schwarz
- DIN Größe:
- 2 DIN
- Ausgangsleistung:
- 45 W
- Lautstärkeregler:
- Drehregler
- Uhrmodus:
- 12 h / 24 h
- Playback MP3:
- Ja
- USB-unmittelbare Wiedergabe:
- Ja
- Eingebautes Display:
- Ja
- Display-Typ:
- Fluoreszierend
- Bildschirmdiagonale:
- 17,1 cm (6.75 Zoll)
- LED-Hintergrundbeleuchtung:
- Ja
- Breite:
- 178 mm
- Tiefe:
- 75 mm
- Höhe:
- 100 mm
- Gewicht:
- 1,1 kg
- Paketgewicht:
- 1,3 kg
- Bildschirmdiagonale in Zoll:
- 6.8
- USB-Version:
- ja
- Monitor-Typ:
- starrer Monitor
- Monitor-Format:
- 16:9
- Größe in DIN:
- 2
- Bluetooth:
- ja
- Produkttyp:
- Moniceiver
- MP3 Wiedergabe:
- ja
- Touchscreen:
- Multi-Touch
- Sprachsteuerung:
- Komplettsteuerung
- Integriertes Radio:
- ja
- iPod/iPhone-Steuerung:
- direkte Steuerung
- Apps Control:
- volle Steuerung
- Mirror Link:
- ja
- Screen Mirroring:
- ja
- Apple Car Play:
- ja
- Hochauflösende Audio-Wiedergabe:
- ja
- Android Auto:
- ja
- Mechaless:
- ja
- Wiedergabeformate:
- Bildschirmgröße in cm:
- Bildschirmgröße:
